ELEK Software (ex. Electrotechnik) Cable High Voltage v7.0 build 29.09.2024
ELEK Cable High Voltage is advanced power cable design and electrical engineering software developed for calculating cable ampacity, current-carrying capacity, thermal performance, and temperature distribution in low-, medium-, and high-voltage cable systems, including HVAC and HVDC power cables. It helps electrical engineers determine safe continuous, emergency, and cyclic current ratings under different installation and environmental conditions.
Featuring powerful cable thermal analysis, electrical loss calculations, and heat transfer modeling, ELEK Cable High Voltage evaluates cable conductor materials, insulation types, screen configurations, soil thermal resistivity, burial depth, cable spacing, bonding methods, ducts, and thermal backfill. Its calculation methods support industry-standard IEC 60287 and IEC 60853, as well as Neher–McGrath and Finite Element Method (FEM) analysis.
Key capabilities include steady-state ampacity calculations, emergency and cyclic loading analysis, soil dry-out assessment, cable modeling, magnetic field calculations, and cable crossing analysis. With specialized tools for underground and high-voltage power cable systems, ELEK Cable High Voltage is an essential engineering solution for power transmission design, cable rating calculations, electrical network planning, and thermal analysis of high-voltage cable installations.
