OverCAD PDF to DWG Converter 2.0.6 + Portable


Portable OverCAD PDF to DWG Converter 2.0.6--All Windows(x32/x64) --rar--6.8 mb
OverCAD PDF to DWG Converter - allows you convert PDF to DWG. Support PDF line, rectangle, ellipse, round rectangle, line segments, bezier segments, image and text etc.


​


OverCAD PDF TO DWG Converter is a software application with a name that perfectly explains its functionality - it allows you to turn PDF files into drawings supported by AutoCAD (DWG).
The interface of the program is based on a standard window and an intuitive layout. Adding files to the list can be done by using either the file browser or tree view, since the 'drag and drop' method is unsupported. It is possible to work with multiple items at the same time.
The file queue provides the soure path and status of each item. So, all you have to do is establish the output directory, and proceed with the conversion procedure. In addition, you can remove an item from the list or clear the entire file queue.
The program runs on low-to-moderate amount of system resources, has a good response time and quickly finishes a task. We have not come across any issues during our tests; OverCAD PDF TO DWG Converter did not freeze, crash or display error dialogs. The output files have a good quality regarding graphics.
On the downside, OverCAD PDF TO DWG Converter has very limited features. For instance, you cannot preview the initial or output files, make the app minimize to the system tray or open the target location when all tasks are done. Nevertheless, first-time users may seamlessly get familiarized with the tool's features, thanks to the intuitive layout and overall simplicity.

Features:
Convert PDF file to native DWG file.
Import PDF file to AutoCAD directly.
High quality, easy to use.
Batch conversion.
Support bezier segments.
Support text font style.
Support images.
Generate DWG file quick and small.

Why some PDF files can just convert to images?

If some one use software convert DWG to PDF and the internal process is DWG to Image(JPG or GIF), then convert the Image to PDF. Then these PDF files can’t convert back to DWG beacause it’s raster image now. But if the DWG is converted direct to PDF and no Image as the intermediate result then these PDF can convert back to DWG.


System Requirements
IBM or compatible Pentium/AMD processor (900 MHz or greater), 512 MB RAM or greater. 1024 x 768, 16-bit display (32-bit recommended)
Windows XP
Windows Vista all SP
Windows 7
Language English


6.8MB
