    MECA MecaLug v1039

    MecaLug is a Padeye or Lifting Lug Calculation Software package that is used to perform padeye or lifting lug calculations as well as analyze loads acting on padeyes or lifting lugs for a structure or piece of equipment. Several different styles of padeyes or lifting lugs are offered giving the user multiple options in selecting an appropriate lifting lug.




    There are also several different configurations in the MecLug Software for different equipment and structures. The lifting lug software even has templates for lifting a stack or cylindrical vessel from horizontal to vertical, using either lifting lugs or lifting trunnions. For this special type of lifting of stacks, the lifting lug software considers the multiple angles as the structure rotates from horizontal to vertical in order to find the worst angle on the lifting lugs/trunnions and tailing lug.

    MecaLug Standard version is the least expensive version of the software that allows the user to perform Padeye / lifting lug calculations per ASME BTM-1 "Design of Below-the-Hook Lifting Devices”. Engineers often design structures and equipment for extreme wind, seismic and other loading that may never occur; however, in the case of a lifting lug those extreme loads may very well be experienced at the beginning of the equipment life cycle, not in 20+ years down the road. The failure of a lifting lug could very likely put human life in danger in the event of a failure. The lifting lug software allows the user to quickly and accurately analyze Padeye / lifting lugs for a variety of loads.

    MecaLug Pro version offers the same features of the standard version of the lifting lug software of analyzing a single lug or trunnion, but MecaLug Pro also has the added benefit of being able to apply those lugs to a lifting system and analyze what loads would be seen by the crane, cable, and lugs. This Pro feature of the MecaLug allows the designer to consider lifting a piece of equipment or structure, and have the software determine the loads acting on each individual lug. The analysis of each lug is then performed by the lifting lug software. The Pro features make MecaLug an all-in-one lifting lug software.


    Size: 70 MB

    Download

    http://s6.alxa.net/one/2022/12/MECA.MecaLug.v1039.rar
