Revit Mep - Mechanical / Hvac Systems

Energy and mechanical design with BIM

What you'll learn
Create templates with settings suitable for mechanical design
Carry out energy analysis based on building data
Create thermal load reports
Export to external simulation software using gbXML
Create mechanical systems within Revit
Create piping system for mechanical installations
Design duct and pipe sizes from BIM model





Requirements
It is advantageous to be familiar with the Revit environment
It is necessary to have Revit 2020 or higher to open the exercise files


Description
In this course we will concentrate on the use of Revit tools that assist us in performing energy analysis of buildings.

We will see how to enter energy information in our model and how to export this information for treatment outside of Revit.#...In the final section, we will pay attention to creating logical duct and pipe systems, creating those elements, and using the Revit engine to design sizes and verify performance.content: Lecture 1: Introduction Lecture 2: Templates with mechanical configurations Lecture 3: Links for collaborative work Lecture 4: Create spaces Lecture 5: Place spaces Lecture 6: Create space tables Lecture 7: Modify space properties Lecture 8: Create zones Lecture 9: Modify construction options Lecture 10: Thermal load analysis Lecture 11: Load analysis Lecture 12: Climate data Lecture 13: Sliver spaces Lecture 14: Level of detail of the report Lecture 15: Load analysis details Lecture 16: Thermal load reports Lecture 17: Export gbXML to simulation software Lecture 18: Systems Explorer Lecture 19: Mechanical configurations Lecture 20: Duct connectors Lecture 21: Create mechanical systems Lecture 22: Mechanical piping configuration Lecture 23: Pipe connectors Lecture 24: Piping systems Lecture 25: Place terminals Lecture 26: Place mechanical equipment Lecture 27: Create routing scheme Lecture 28: Manual routing Lecture 29: Duct sizes Lecture 30: Mechanical piping equipment Lecture 31: Mechanical pipe routing Lecture 32: Manual pipe editing Lecture 33: Mechanical pipe size Lecture 34: Loss reports Lecture 35: Farewell


Overview

Section 1: Introduction

Lecture 1 Introduction

Lecture 2 Templates with mechanical configurations

Lecture 3 Links for collaborative work

Section 2: Energy Design

Lecture 4 Create spaces

Lecture 5 Place spaces

Lecture 6 Create space tables

Lecture 7 Modify space properties

Lecture 8 Create zones

Lecture 9 Modify construction options

Lecture 10 Thermal load analysis

Lecture 11 Load analysis

Lecture 12 Climate data

Lecture 13 Sliver spaces

Lecture 14 Level of detail of the report

Lecture 15 Load analysis details

Lecture 16 Thermal load reports

Lecture 17 Export gbXML to simulation software

Section 3: Design of mechanical installations

Lecture 18 Systems Explorer

Lecture 19 Mechanical configurations

Lecture 20 Duct connectors

Lecture 21 Create mechanical systems

Lecture 22 Mechanical piping configuration

Lecture 23 Pipe connectors

Lecture 24 Piping systems

Lecture 25 Place terminals

Lecture 26 Place mechanical equipment

Lecture 27 Create routing scheme

Lecture 28 Manual routing

Lecture 29 Duct sizes

Lecture 30 Mechanical piping equipment

Lecture 31 Mechanical pipe routing

Lecture 32 Manual pipe editing

Lecture 33 Mechanical pipe size

Lecture 34 Loss reports

Section 4: Conclusion

Lecture 35 Farewell

BIM managers,BIM modelers,HVAC Modeler,REVIT/BIM Mechanical Modeler,HVAC Draftsman


Last updated 6/2020
MP4 | Video: h264, 1280x720 | Audio: AAC, 44.1 KHz
Language: English | Size: 2.34 GB | Duration: 3h 44m
