    Mentor Graphics PADS VX 2.10 includes Update_1

    Year / Release Date: 2021/10/18
    Version: 2.10 Build Update 1
    Developer: Siemens Digital Industries Software
    Developer site: eda.sw.siemens.com/en-US/pcb/pads/standard-plus/
    Bit depth: 32bit
    Interface language: Multilingual (Russian is present)
    Tabletka: present

    Mentor Graphics PADS VX 2.10 includes Update_1


    System requirements:
    Windows:
    Processor: Dual-core Intel or AMD processor minimum.
    Memory: 8GB recommended
    Swap Space: 2x the amount of RAM


    Description:
    PADS Standard and Standard Plus VX 2.10 Update 1
    PADS is the leading platform for creating high quality electronic products. With PADS PCB design tools, you can create anything you can dream of, from the very simple to the very complex.
    Long a part of Mentor PCB, PADS benefits from continuous development and global distribution.

    Code:
    The main advantages of the product
    • Schematic design
    • Online modeling of PADS AMS Cloud circuits
    • PCB layout
    • Selection and verification of components
    • Creation of an individual land mass in accordance with the requirements of the IPC.
    • Integrated constraint management
    • Limitations on high speed and routing
    • Signal integrity analysis with crosstalk using HyperLynx®
    • Thermal and analog simulation
    • Central Library
    Code:
    What's New in PADS Std and Std Plus VX.2.10 (October 2021)
    PADS Designer:
    Improved settings display
    • The Settings> Preferences and Display Control options have been reorganized and redundant settings have been removed.
    Improved properties window
    • If multiple symbols are selected and their property values ​​have different visibility states, the visibility flag shows a filled square as an indicator.
    improved search box
    • Eliminate duplicate rows of component parametric data by concatenating identical rows.
    central Library
    Improved Library Migration Wizard
    • Added transfer from CADStar, OrCAD, PCAD and Eagle libraries directly to a new or existing central library.
    AMS COVERINGS:
    Editing properties with multiple symbols
    • The "Model Properties" dialog box now supports editing properties for
    several characters at the same time.
    Installation Scheme Wizard Updates
    • Setting up a schematic for simulation has become more intuitive with the changes in the schematic wizard.
    VHDL-AMS language support
    • Support: records, arrays of records, interrupt lists.
    SimDB Mapping File Updates
    • Apply mapping information to the entire project, selected schematic sheets, or selected components.
    Simulator updates
    • Support for global terminals when using noinclib and save / restart for digital and array signals.
    SPICE model support
    • The ASM-HEMT SPICE model is now part of the PADS AMS model library.
    SI module Netlisting support
    • New checkbox "Use SI units for model parameter values" in
    Netlist Header Setup dialog box for selecting SI units for property values.

    Size: 7.95 GB
