    Inus Rapidform XOR3 SP1 x64

    Rapidform XOR, package 3G (third generation) for reverse engineering, is a complete software to create CAD models from 3D scan data. With Rapidform XOR, you can open data from any 3D-scanner and easily create editable, parametric solid models of virtually any physical object.

    These models can be transferred from XOR into popular applications CAD, including SolidWorks ®, Siemens NX ™, Pro / ENGINEER ®, CATIA ® V4, CATIA V5 ® and AutoCAD ® full tree.

    This means that - unlike second generation reverse engineering model XOR can be edited like any other CAD software. From XOR can save models Parasolid ®, STEP, IGES and STL for use in any CAD / CAM / CAE application.

    Engineering approach to XOR allows you to create high-quality, ready-to-manufacture CAD model, quickly and easily. Creating a full solid model to within a few microns, according to the 3D scan takes less time than rebuilding it in CAD.

    XOR, in combination with 3D-scanner, the fastest, most accurate way to create a design model of the object in the real world

    Inus Rapidform XOR3 SP1 x64
    Year / Release Date: 2012


    Developer: INUS Technology Inc.

    Developer website: rapidform.com

    Bit: 64bit

    Language: English Russian

    Medicine: Present

    System requirements
    - Intel® and AMD® processors.
    - Multi processors recommended for greater performance
    - Minimum: 1 GB
    - Recommended: 2 GB
    - Virtual Memory; XP: recommended to 2.5 times the amount of RAM Vista,
    Win7: recommended to use the default option; "Automatically manage paging file size for all drives"
    Hard Disk
    - 30 GB or more recommended
    - Temporary file cache requires about 3 GB free disk space for every 100 million points
    - A fast hard drive such as SSD or more than 10000 RPM HDD may help to enhance the performance
    - Recommended using multiple hard drives so that you can assign a "cache" drive for Rapidform temporary
    storage and paging files to a hard drive different from the one for operating system installed for the better performance
    - OpenGL 1.2 or above, 32 bit true color required
    - Recommended 24-inch wide screen monitor, 1920X1280 resolution
    Graphics Card
    - OpenGL 1.2 or above
    - NVIDIA GeForce 4 or above
    - ATI Radeon 9600 or aboveRecommended:
    - 512 MB or higher graphic memory
    - OpenGL 2.0 or above
    - NVIDIA GeForce 6600 or above
    - ATI Radeon X1650 or above
    Extras. info
    The full version of the program with all the tutorials
