Flow of Fluids Excel Workbook
What you'll learn
Determine the main physical properties of fluids (viscosity, vapor pressure, specific gravity, weight density...)
Assess the theory of flow in pipe : Laminar vs Turbulent flow
Use the Bernoulli Theorem to calculate pressure drop, head loss or flow velocity
Calculate the pressure drop "dP" and the head loss "hL" through any piping system
Determine the friction factor "f" of any piping system
Calculate the flow of compressible and incompressible fluids in pipe
Calculate the resistance coefficient "K" of any piping component (pipes, valves, bends, reducers, Tees, Wyes...)
Calculate the flow coefficient "Cv" of a control valve and use it in assessing flows and pressure drops
Size and select a control valve when designing and operating any piping system for both gases and liquids
Calculate the flow of compressible and incompressible fluids through Orifice Plates, Flow Nozzles and Venturi Meters
Size and select a flow meter when designing and operating any piping system for both gases and liquids
Requirements
Some engineering or field knowledge is preferable but not mandatory. All the concepts are explained in depth using an easy to understand language to allow students to build their knowledge from the ground up
Having attended our "Flow of fluids through piping systems, valves and pumps" training course is a plus but not mandatory
Having attended our "Piping Systems : Drafting & Design" training course is a plus but not mandatory
Having attended our "Valves : Principles, Operation & Design" training course is a plus but not mandatory
Description
Dear students,
To accompany our course on Flow of fluids through pipe, fittings, valves and pumps and help you assess flow of liquids and gases, calculate pressure drops, size pipes, control valves and flow meter devices, we have developed an Excel VBA based engineering tool :
Flow of Fluids Excel Workbook
Flow of Fluids Excel Workbook simulates the operation of small piping systems transporting liquids and industrial gases under a variety of operating conditions.
Flow of Fluids Excel Workbook is based on industry recognized principles and standards from ASME, HI, IEC, AWWA, ISA, and ANSI...
Flow of Fluids Excel Workbook is easy-to-use and has a highly intuitive user interface.
Flow of Fluids Excel Workbook presents formulas and data for :
IMPORTANT NOTE :
The video lectures included in this materiel are quick tutorials to show you how to use the Flow of Fluids Excel Workbook.
Please watch these videos and follow the instructions provided. In case of any problem, feel free to ask us for help in the Q&A section.
This Excel workbook includes Visual Basic for Application function subroutines. Macros must be enabled for them to work
ENJOY THIS AMAZING TOOL :-)
FLOW OF FLUIDS EXCEL WORKBOOK : TABLE OF CONTENT
An Excel VBA based engineering tool by WR Training
DISCLAIMER
This software is provided by WR Training "as is" and any express or implied warranties, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose are disclaimed. In no event shall the Copyright owner or contributors be liable for any direct, indirect, incidental, special, exemplary, or consequential damages (including, but not limited to, procurement of substitute goods or services, loss of use, data, or profits, or business interruption) however caused and on any theory of liability, whether in contract, strict liability, or tort (including negligence or otherwise) arising in any way out of the use of this software, even if advised of the possibility of such damage.
Who this course is for:
Chemical, Process, Petroleum Engineers
Design Engineers
Piping Engineers
Plant Engineers
Facility Managers
Maintenance Technicians
Mechanics
Plant Operators
Safety Engineers
Recent College Graduates
MP4 | h264, 1280x720 | Lang: English | Audio: aac, 44100 Hz | 1h 4m | 720 MB
Download
http://s9.alxa.net/0abc1/xyza/Flow.o...l.Workbook.rar
What you'll learn
Determine the main physical properties of fluids (viscosity, vapor pressure, specific gravity, weight density...)
Assess the theory of flow in pipe : Laminar vs Turbulent flow
Use the Bernoulli Theorem to calculate pressure drop, head loss or flow velocity
Calculate the pressure drop "dP" and the head loss "hL" through any piping system
Determine the friction factor "f" of any piping system
Calculate the flow of compressible and incompressible fluids in pipe
Calculate the resistance coefficient "K" of any piping component (pipes, valves, bends, reducers, Tees, Wyes...)
Calculate the flow coefficient "Cv" of a control valve and use it in assessing flows and pressure drops
Size and select a control valve when designing and operating any piping system for both gases and liquids
Calculate the flow of compressible and incompressible fluids through Orifice Plates, Flow Nozzles and Venturi Meters
Size and select a flow meter when designing and operating any piping system for both gases and liquids
Requirements
Some engineering or field knowledge is preferable but not mandatory. All the concepts are explained in depth using an easy to understand language to allow students to build their knowledge from the ground up
Having attended our "Flow of fluids through piping systems, valves and pumps" training course is a plus but not mandatory
Having attended our "Piping Systems : Drafting & Design" training course is a plus but not mandatory
Having attended our "Valves : Principles, Operation & Design" training course is a plus but not mandatory
Description
Dear students,
To accompany our course on Flow of fluids through pipe, fittings, valves and pumps and help you assess flow of liquids and gases, calculate pressure drops, size pipes, control valves and flow meter devices, we have developed an Excel VBA based engineering tool :
Flow of Fluids Excel Workbook
Flow of Fluids Excel Workbook simulates the operation of small piping systems transporting liquids and industrial gases under a variety of operating conditions.
Flow of Fluids Excel Workbook is based on industry recognized principles and standards from ASME, HI, IEC, AWWA, ISA, and ANSI...
Flow of Fluids Excel Workbook is easy-to-use and has a highly intuitive user interface.
Flow of Fluids Excel Workbook presents formulas and data for :
Code:
1. Physical properties determination for a variety of fluids (specific gravity, viscosity, vapor pressure...) 2. Pressure drop and head loss calculations through pipes, fittings and valves 3. Flow calculations for incompressible and compressible fluids through pipes, fittings, valves and pumps 4. Sizing piping systems for incompressible and compressible fluids 5. Flow resistance coefficients calculations for pipes, fittings and valves 6. Flow calculations for incompressible and compressible fluids through flow meters (Orifice Plates, Nozzles and Venturi meters) 7. Centrifugal pump calculation (Pump head, NPSH, Specific speed, affinity laws…) 8. Converting variables and process parameters to a numerious alternative units of measurement INSTRUCTION TO DOWNLOAD FLOW OF FLUIDS EXCEL WORKBOOK : 1. Upon enrolling in, expand the first section "ABOUT THE FLOW OF FLUIDS" 2. Under the lecture "Presentation", click on the folder "resources" => A list of 3 downloadable files will appear 3. Click on "Flow of Fluids Excel Workbook" 4. A download window will open. Select the location where you want to save the Excel file 5. Once downloaded and saved on your computer, you can start using the file
The video lectures included in this materiel are quick tutorials to show you how to use the Flow of Fluids Excel Workbook.
Please watch these videos and follow the instructions provided. In case of any problem, feel free to ask us for help in the Q&A section.
This Excel workbook includes Visual Basic for Application function subroutines. Macros must be enabled for them to work
ENJOY THIS AMAZING TOOL :-)
FLOW OF FLUIDS EXCEL WORKBOOK : TABLE OF CONTENT
An Excel VBA based engineering tool by WR Training
Code:
A. PHYSICAL PROPERTIES OF FLUIDS 1 PROPERTIES OF WATER AND STEAM a. SATURATION PROPERTIES WITH TEMPERATURE b. SATURATION PROPERTIES WITH PRESSURE c. PROPERTIES GIVEN PRESSURE AND TEMPERATURE d. PROPERTIES GIVEN PRESSURE AND ENTHALPY 2 DYNAMIC VISCOSITY OF GASES 3 KINEMATIC VISCOSITY 4 WEIGHT DENSITY OF LIQUIDS a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 5 SPECIFIC GRAVITY OF LIQUIDS a. FORMULA 1 b. FORMULA 2 6 SPECIFIC GRAVITY - DEG API 7 SPECIFIC GRAVITY - DEG BEAUME 8 SPECIFIC VOLUME 9 WEIGHT DENSITY OF IDEAL GASES 10 WEIGHT DENSITY OF REAL GASES 11 GAS COMPRESSIBILITY FACTOR 12 SPECIFIC GRAVITY OF GASES 13 BOILING POINT PURE COMPONENT 14 VAPOR PRESSURE : PURE COMPONENT 15 VAPOR PRESSURE : MIXTURE B. NATURE OF FLOW IN PIPE 1 RATE OF FLOW AT FLOWING CONDITION a. FORMULA 1 b. FORMULA 2 2 RATE OF FLOW (gpm) a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 3 MEAN VELOCITY OF FLOW IN PIPE a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 4 REYNOLDS NUMBER a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 d. FORMULA 4 e. FORMULA 5 f. FORMULA 6 g. FORMULA 7 C. BERNOULLI'S THEOREM 1 TOTAL HEAD OR FLUID ENERGY 2 LOSS OF STATIC PRESSURE HEAD (hL) DUE TO FLUID FLOW D. HEAD LOSS, PRESSURE DROP AND FRICTION FACTOR THROUGH PIPE 1 LOSS OF STATIC PRESSURE HEAD a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 d. FORMULA 4 e. FORMULA 5 f. FORMULA 6 2 PIPE PRESSURE DROP a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 d. FORMULA 4 e. FORMULA 5 f. FORMULA 6 g. FORMULA 7 3 PRESSURE DROP FOR LAMINAR FLOW ACCORDING TO POISEUILLE'S LAW 4 PRESSURE DROP FOR TURBULENT FLOW ACCORDING TO HAZEN-WILLIAMS FORMULA 5 FRICTION FACTOR FOR LAMINAR FLOW 6 FRICTION FACTOR FOR TURBULENT FLOW a. COLEBROOK EQUATION b. SERGHIDE EQUATION c. SWAMEE-JAIN EQUATION E. GAS CALCULATIONS 1 PERFECT GAS LAW a. DETERMINING THE NUMBER OF MOLES OF A PERFECT GAS b. DETERMINING THE PRESSURE OF A PERFECT GAS c. DETERMINING THE TEMPERATURE OF A PERFECT GAS d. DETERMINING THE VOLUME OF A PERFECT GAS 2 NON-IDEAL GAS LAW a. DETERMINING THE NUMBER OF MOLES OF A NON-IDEAL GAS b. DETERMINING THE PRESSURE OF A NON-IDEAL GAS c. DETERMINING THE TEMPERATURE OF A NON-IDEAL GAS d. DETERMINING THE VOLUME OF A NON-IDEAL GAS 3 STANDARD ◄►ACTUAL GAS FLOW F. COMPRESSIBLE FLOW IN STRAIGHT HORIZONTAL PIPELINE 1 COMPLETE ISOTHERMAL EQUATION G. GAS PIPELINES : MASS FLOW RATE EQUATION H. HORIZONTAL GAS PIPELINES : STANDARD VOLUMETRIC FLOW RATE EQUATIONS 1 GENERAL STANDARD VOLUMETRIC FLOW RATE 2 WEYMOUTH STANDARD VOLUMETRIC FLOW RATE EQUATION FOR SIZING HORIZONTAL GAS PIPELINES IN FULLY TURBULENT FLOW 3 PANHANDLE "A" STANDARD VOLUMETRIC FLOW RATE EQUATION FOR SIZING HORIZONTAL GAS PIPELINES IN PARTIALLY TURBULENT FLOW 4 PANHANDLE "B" STANDARD VOLUMETRIC FLOW RATE EQUATION FOR SIZING HORIZONTAL GAS PIPELINES IN FULLY TURBULENT FLOW I. ELEVATED GAS PIPELINES : STANDARD VOLUMETRIC FLOW RATE EQUATION J. LIQUID FLOW THROUGH ORIFICES K. LIQUID FLOW THROUGH ISA 1932 NOZZLES L. LIQUID FLOW THROUGH LONG RADIUS NOZZLES M. LIQUID FLOW THROUGH VENTURI NOZZLES N. LIQUID FLOW THROUGH VENTURI METERS O. GAS FLOW THROUGH ORIFICES P. GAS FLOW THROUGH ISA 1932 NOZZLES Q. GAS FLOW THROUGH LONG RADIUS NOZZLES R. GAS FLOW THROUGH VENTURI NOZZLES S. GAS FLOW THROUGH VENTURI METERS T. RESISTANCE COEFFICIENT FOR PIPES, VALVES AND FITTINGS 1 CONTRACTION 2 ENLARGEMENT 3 GATE VALVES 4 GLOBE AND ANGLE VALVES 5 SWING CHECK VALVES 6 LIFT CHECK VALVES 7 TILTING DISC CHECK VALVES 8 STOP CHECK VALVES 9 FOOT VALVES WITH STRAINER 10 BALL VALVES 11 BUTTERFLY VALVES 12 DIAPHRAGM VALVES 13 PLUG VALVES 14 MITRE BENDS 15 90° PIPE BEND AND FLANGED OR BW 90° ELBOWS 16 MULTIPLE 90° PIPE BENDS 17 CLOSE PATTERN RETURN BENDS 18 STANDARD ELBOWS 19 PIPE ENTRANCE 20 PIPE EXIT 21 TEES AND WYES - CONVERGING FLOW 22 TEES AND WYES - DIVERGING FLOW 23 ORIFICES, NOZZLES AND VENTURIS U. HEAD LOSS AND PRESSURE DROP THROUGH VALVES AND FITTINGS 1 LOSS OF STATIC PRESSURE HEAD a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 2 PIPE PRESSURE DROP a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 V. FLOW OF FLUIDS THROUGH VALVES, FITTINGS AND PIPE 1 LIQUID FLOW THROUGH A VALVE, FITTINGS AND PIPE a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 d. FORMULA 4 e. FORMULA 5 f. FORMULA 6 g. FORMULA 7 2 GAS FLOW THROUGH A VALVE; FITTINGS AND PIPE a. FORMULA 1 b. FORMULA 2 c. FORMULA 3 3 VALVE FLOW COEFFICIENT "Cv" a. FORMULA 1 b. FORMULA 2 4 VALVE RESISTANCE COEFFICIENT "K" W. CALCULATIONS FOR CENTRIFUGAL PUMP 1 PUMP HEAD a. HEAD FORMULA b. PUMP IN SUCTION HEAD c. PUMP IN SUCTION LIFT 2 PUMP DISCHARGE PRESSURE 3 NET POSITIVE SUCTION HEAD REQUIRED 4 NET POSITIVE SUCTION HEAD AVAILABLE 5 TOTAL DYNAMIC HEAD 6 SUCTION SPECIFIC SPEED (Nss) 7 SPECIFIC SPEED (Ns) X. PUMP AFFINITY LAWS 1 IMPACT OF SPEED ON FLOW 2 IMPACT OF SPEED ON HEAD 3 IMPACT OF SPEED ON BHP 4 IMPACT OF IMPELLER DIAMETER ON FLOW 5 IMPACT OF IMPELLER DIAMETER ON HEAD 6 IMPACT OF IMPELLER DIAMETER ON BHP 7 PUMP BRAKE HORSPOWER 8 PUMP EFFICIENCY Y. FLOW OF WATER THROUGH SCHEDULE 40 STEEL PIPE 1 CALCULATIONS FOR PIPE OTHER THAN SCHEDULE 40 Z. FLOW OF AIR THROUGH SCHEDULE 40 STEEL PIPE 1 CALCULATIONS FOR PIPE OTHER THAN SCHEDULE 40 2 CALCULATIONS FOR OTHER SET OF TEMPERATURE AND PRESSURE 3 FROM STANDARD TO ACTUAL VOLUME FLOW ZZ. CONVERSION TABLES 1 LENGTH 2 AREA 3 VOLUME 4 VELOCITY 5 MASS 6 MASS FLOW RATE 7 VOLUMETRIC FLOW RATE 8 FORCE 9 PRESSURE AND LIQUID HEAD 10 ENERGY, WORK AND HEAT 11 POWER 12 WEIGHT DENSITY 13 TEMPERATURE 14 DYNAMIC VISCOSITY 15 KINEMATIC VISCOSITY
This software is provided by WR Training "as is" and any express or implied warranties, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose are disclaimed. In no event shall the Copyright owner or contributors be liable for any direct, indirect, incidental, special, exemplary, or consequential damages (including, but not limited to, procurement of substitute goods or services, loss of use, data, or profits, or business interruption) however caused and on any theory of liability, whether in contract, strict liability, or tort (including negligence or otherwise) arising in any way out of the use of this software, even if advised of the possibility of such damage.
Who this course is for:
Chemical, Process, Petroleum Engineers
Design Engineers
Piping Engineers
Plant Engineers
Facility Managers
Maintenance Technicians
Mechanics
Plant Operators
Safety Engineers
Recent College Graduates
