    ASDIP Structural Concrete v4.4.8

    ASDIP Structural Foundation v4.4.2

    ASDIP Structural Retain v4.7.6

    ASDIP Structural Steel v5.0.5





    ASDIP STEEL is structural engineering software utilized by engineers for design of steel base plate, steel and composite beam, steel columns, and other structural steel members. ASDIP STEEL is based upon the latest AISC specifications (AISC 360). ASDIP STEEL substantially simplifies time-consuming calculations for structural engineering design.


    ASDIP Foundation is a suite of modules specifically dedicated to the design of concrete footings, based on the latest IBC / ACI 318 specifications, that greatly simplifies the time-consuming calculations in any structural engineering office. ASDIP Foundation includes the design of the following types of concrete footings:
    - Spread Footings: Design of a concrete spread footing under the action of vertical load, horizontal load and biaxial bending. This module designs the footing per the load combinations of the ASCE 7.

    - Strap Footings: Design of a concrete strap footing under the action of vertical loads, horizontal loads and bending moments. This module designs the two footings and the strap beam per the load combinations of the ASCE 7.Combined Footings: Design of a concrete combined footing under the action of vertical loads, horizontal loads and bending moments. This module designs the combined footing per the load combinations of the ASCE 7.


    ASDIP Concrete is a suite of modules specifically dedicated to the design of concrete members such as beams, columns and walls, based on the latest ACI 318 specifications, that greatly simplifies the time-consuming calculations in any structural engineering office. ASDIP Concrete includes the design of the following types of concrete elements:




    Code:
    * Concrete Columns: design of a concrete column under the action of axial loads and bending moments. This module calculates the magnified moments for slenderness of ASCE 7 load combinations, and generates the column strength interaction diagram.
    * Concrete Beams: design of a concrete muti-span continuous beam under the action of uniform and concentrated loads. This module accurately calculate the bending and shear strength for different types of beams. Load combinations per ASCE 7.
    * Bearing Walls: design of a concrete wall under the action of vertical and out-of-plane lateral loads. This module calculates the magnified moments for slenderness of ASCE 7 load combinations, and generates the wall strength interaction diagram.



    ASDIP Concrete is an integrated, interactive system that combines the flexibility of a fill-in-the-blanks format with the power of Windows Forms to effortlessly develop either an optimal design or a quick investigation.
    Using a screen with tabbed pages, ASDIP Concrete allows you enter your data directly onto the forms and see the result immediately.

    This way you are always in control of the design process, since what you see is really what you get. In addition, the detailed results and the graphics are always available for you to follow by the touch of a tab.


    ASDIP Retain is a suite of modules specifically dedicated to the design of retaining walls, based on the latest IBC / ACI 318 specifications, that greatly simplifies the time-consuming calculations in any structural engineering office. ASDIP Retain includes the design of the following two types of retaining walls:
    - Cantilever Retaining Walls: Design of a retaining wall supported only at the base under the combination of earth pressure, surcharge, wind and seismic loads. The module designs the wall per the load combinations of the ASCE 7.

    - Restrained Retaining Walls: Design of a retaining wall supported at the base and laterally restrained at the top, also known as a basement wall, under the combination of earth pressure, surcharge, wind and seismic loads. The module designs the wall per the load combinations of the ASCE 7.


    60MB

    Download
    http://s9.alxa.net/0abc1/xyza/ASDIP.v4.4.8.rar
