AISC 360/341-16. This release includes the latest edition of the Specification for Structural Steel Buildings of the American Institute of Steel Construction (Allowable Strength Design (ASD), Load and Resistance Factor Design (LRFD)), as well as the most recent edition of the Seismic Provisions for Structural Steel Buildings. Torsional analysis per DG 9 is also included.
AISI S100-16. This release also includes the latest edition of the North American Specification for the Design of Cold-Formed Steel Structural Members of the American Iron and Steel Institute (Allowable Strength Design (ASD) and Load and Resistance Factor Design (LRFD)).
64-bit Version. RAM Elements is now compiled in 64 bits and fully compatible with 64-bit versions of Windows.
New File Format. RAM Elements’ models are now in SQLite format which are smaller in size and frequently faster to read and write. This modification caused a change in the file extension of the files from *.ETX to *.RETX.
Automatic Mass Generation without Diaphragm. Addition to generate masses used in dynamic analysis for structures without rigid diaphragms, by using element’s (members and shells) self-masses.
Automatic Wind Load Generation. RAM Elements now includes tools to generate wind loads in closed (using the existing load areas feature) and open (using the member distributed loads feature) structures per ASCE 7-16.
ISM 6.0 Enhancements. RAM Elements now synchronizes concrete reinforcement steel bars for beams and columns as well as built-up sections and tapered members.
Center of Rigidity. The software can now report the center of rigidity for each rigid diaphragm.
New Modeling Tools. The selection of invalid (missing section or material) members and invalid (missing nodes, material or thickness) shells is now possible. The ability to copy in a circular or spiral fashion is also part of this release.
New Themes. RAM Elements now ships with three color themes that can be selected in the Configuration dialog.
Beam Design Module. The ability to show the reinforcement outside the beam for better detailing as it was possible in older versions of the software (RAM Advanse) is now back.
Masonry Wall Module. 4 inches block units have been added to the block database.
