Concrete Beam Design Spreadsheet is a spreadsheet program written in MS-Excel for the purpose of analysis/design of rectangular beam or column sections. Specifically, the required flexural reinforcing, ultimate moment capacity, bar spacing for crack control, moments of inertia for deflection, beam shear and torsion requirements, and member capacity for flexure (uniaxial and biaxial) with axial load are calculated. There is also a worksheet which contains reinforcing bar data tables.



Content



Beam flexure, shear, crack control, and inertia

Flexural reinforcing for singly or doubly reinforced beams/sections

Ultimate moment capacity of singly or doubly reinforced beams/sections

Crack control – distribution of flexural reinforcing

Beam or one-way type shear

Beam torsion and shear

Moments of inertia of singly or doubly reinforced beams/sections

Combined uniaxial flexure and axial load

Combined biaxial flexure and axial load

Reinforcing bar data tables
