    Boole StairDesigner Pro-RB 6.51








    Description

    CAD\CAM Load a DWG file into this application and you will be able to convert it to DWF, PDF, JPEG, and other formats. You can use StairDesigner is a polyvalent straight, helicoidal, and balanced stair design software, used in the wood, marble, stone, and metal industries.
    StairDesigner allows a quick stairway parameters entry. Its Help and Control Function checks the Riser Height, Tread Length, and Stair Rule parameters (Blondel’s law), and helps reaching the stair compliance.

    StairDesigner, Stair Design to Measure

    StairDesigner is based on the Boole & Partners exclusive Global Balancing Function, which summarizes major balancing theories, and calculates «S-shaped» stairs, cut-off corners stairs, English styled stairs, and rounded stairs, and also optimizes concrete stairs coverage (StairDesigner-Pro_RB).
    StairDesigner calculates all the stair components : steps, risers, stringboards, racks, straws, poles, handrails and banisters, which may be printed, plotted in a scale 1/1 (jigs), or exported in DXF format.
    The StairDesigner 3D integrated function (colors, textures, and transparency levels) displays the stair in various 3D views.

    STAIRDESIGNER MAIN FEATURES

    Help and Control Function :

    StairDesigner controls each of the Riser Height, the Tread Length, and the Stair Rule vis-a-vis [Min - Max] intervals.
    When the stair values comply with the [Min - Max] control intervals (default values as per contra), StairDesigner displays a green signal.

    Global Balancing Function :

    Once the stairway is defined, StairDesigner calculates a stair global balancing. All steps are balanced by default, but each step’s postion may be moved individually : StairDesigner will then automatically recalculate the stair balancing.

    «S shaped» Stairs :

    StairDesigner is able to design up to 7 flights stairs. Each flight is determined by its dimensions, and its angle with the previous flight.
    StairDesigner flights may be defined with an either left or right rotation, enabling «S-shaped» stairs design.



    KeyMaker Included


    2.6MB

    Download
    http://s11.alxa.net/s11/srvs14/001/1...ro-RB.6.51.rar
